Pisa B115
Pisa B115
Pisa B115
Add deep bass and rumble to any system
Add deep bass and rumble to any system
Add deep bass and rumble to any system
Robust bass
Robust bass
Robust bass
Easy Install
Easy Install
Easy Install
Waterproof
Waterproof
Waterproof
Composed of birch wood
Composed of birch wood
Composed of birch wood
Ver./Hor. Installation
Ver./Hor. Installation
Ver./Hor. Installation
Italian-sourced components
Italian-sourced components
Italian-sourced components
Pisa b115 Add deep bass and rumble to any system
Pisa b115 Add deep bass and rumble to any system
Pisa b115 Add deep bass and rumble to any system
The B115 is the perfect choice for you. With its combination of powerful sound and compact design, the B115 promises an unforgettable audio experience.
The B115 is the perfect choice for you. With its combination of powerful sound and compact design, the B115 promises an unforgettable audio experience.
The B115 is the perfect choice for you. With its combination of powerful sound and compact design, the B115 promises an unforgettable audio experience.
Despite its impressive power, the B115 is surprisingly compact at just (W) 595mm x (H) 595mm x (D) 620mm. This makes it easy to place the speaker in any space, from large stages to home listening rooms. The cabinet is crafted from high-quality Baltic birch and poplar wood, giving it a solid and elegant feel.
Despite its impressive power, the B115 is surprisingly compact at just (W) 595mm x (H) 595mm x (D) 620mm. This makes it easy to place the speaker in any space, from large stages to home listening rooms. The cabinet is crafted from high-quality Baltic birch and poplar wood, giving it a solid and elegant feel.
Despite its impressive power, the B115 is surprisingly compact at just (W) 595mm x (H) 595mm x (D) 620mm. This makes it easy to place the speaker in any space, from large stages to home listening rooms. The cabinet is crafted from high-quality Baltic birch and poplar wood, giving it a solid and elegant feel.
ultimate in bass performance
ultimate in bass performance
ultimate in bass performance
The heart of the B115 is a 15-inch driver with an extremely wide operating range. This creates a frequency range of 40Hz-120Hz, delivering deep, tight, and incredibly detailed bass. Whether it's the pounding of drums or the powerful electronic bass, the B115 reproduces it all accurately and vividly
The heart of the B115 is a 15-inch driver with an extremely wide operating range. This creates a frequency range of 40Hz-120Hz, delivering deep, tight, and incredibly detailed bass. Whether it's the pounding of drums or the powerful electronic bass, the B115 reproduces it all accurately and vividly
The heart of the B115 is a 15-inch driver with an extremely wide operating range. This creates a frequency range of 40Hz-120Hz, delivering deep, tight, and incredibly detailed bass. Whether it's the pounding of drums or the powerful electronic bass, the B115 reproduces it all accurately and vividly
Superior power
Superior power
Superior power
Power that can't be ignored: With a peak SPL of up to 132dB, the B115 ensures that your sound will reach every corner of the room. Whether it's a lively party or a large performance, the B115 will make the atmosphere more exciting and energetic.
Power that can't be ignored: With a peak SPL of up to 132dB, the B115 ensures that your sound will reach every corner of the room. Whether it's a lively party or a large performance, the B115 will make the atmosphere more exciting and energetic.
Power that can't be ignored: With a peak SPL of up to 132dB, the B115 ensures that your sound will reach every corner of the room. Whether it's a lively party or a large performance, the B115 will make the atmosphere more exciting and energetic.
Overall assessment
Overall assessment
Overall assessment
The B115 is a wise choice for those who love powerful music and a top-notch bass experience. With its compact design, impressive power, and excellent sound quality, the B115 is worthy of being the "king" of the subwoofer world.
The B115 is a wise choice for those who love powerful music and a top-notch bass experience. With its compact design, impressive power, and excellent sound quality, the B115 is worthy of being the "king" of the subwoofer world.
The B115 is a wise choice for those who love powerful music and a top-notch bass experience. With its compact design, impressive power, and excellent sound quality, the B115 is worthy of being the "king" of the subwoofer world.
impressive bass performance
impressive bass performance
impressive bass performance
A perfect match: The B115 is designed to be the ideal companion for the Pisa B115 speaker system. The similar size and harmonious sound quality help this pair create a professional audio system that meets the needs of listening to music, watching movies, or performing on stage perfectly.
A perfect match: The B115 is designed to be the ideal companion for the Pisa B115 speaker system. The similar size and harmonious sound quality help this pair create a professional audio system that meets the needs of listening to music, watching movies, or performing on stage perfectly.
A perfect match: The B115 is designed to be the ideal companion for the Pisa B115 speaker system. The similar size and harmonious sound quality help this pair create a professional audio system that meets the needs of listening to music, watching movies, or performing on stage perfectly.
Composed of birch wood
Composed of birch wood
All the B Series (B115, S118, S218 and SB136) are made of birch wood, which provides durability over time.
All the B Series (B115, B118, B218 and B136) are made of birch wood, which provides durability over time.
Composed of birch wood
All the B Series (B115, S118, S218 and SB136) are made of birch wood, which provides durability over time.
Key Features
Key Features
Key Features
Robust bass
Robust bass
Robust bass
Robust bass that will shake your walls and make your music come alive.
Robust bass that will shake your walls and make your music come alive.
Robust bass that will shake your walls and make your music come alive.
Composed of birch wood
Composed of birch wood
Composed of birch wood
Birch wood is a hardwood with high durability, able to withstand impact and scratches. This helps the speaker to be used for a long time without damage.
Birch wood is a hardwood with high durability, able to withstand impact and scratches. This helps the speaker to be used for a long time without damage.
Birch wood is a hardwood with high durability, able to withstand impact and scratches. This helps the speaker to be used for a long time without damage.
Easy Install
Easy Install
Easy Install
The installation is made easy with no high technical skills or very special tools needed to install your device.
The installation is made easy with no high technical skills or very special tools needed to install your device.
The installation is made easy with no high technical skills or very special tools needed to install your device.
Ver./Hor. Installation
Ver./Hor. Installation
Ver./Hor. Installation
You can install your speaker on either horizontally or vertically, depending on your installation needs.
You can install your speaker on either horizontally or vertically, depending on your installation needs.
You can install your speaker on either horizontally or vertically, depending on your installation needs.
Waterproof
Waterproof
Waterproof
Using Polyurea Paint technology, resistant to water and high humidity
Using Polyurea Paint technology, resistant to water and high humidity
Using Polyurea Paint technology, resistant to water and high humidity
Italian-sourced components
Italian-sourced components
Italian-sourced components
Italian-sourced components deliver superior sound quality and performance
Italian-sourced components deliver superior sound quality and performance
Italian-sourced components deliver superior sound quality and performance
Technical Specifications
Technical Specifications
Technical Specifications
Name
Name
Name
PISA B115
PISA B115
PISA B115
TYPE
TYPE
TYPE
Compact subwoofer, direct radiating
Compact subwoofer, direct radiating
Compact subwoofer, direct radiating
Frequency Response (+6dB)
Frequency Response (+6dB)
Frequency Response (+6dB)
45 Hz to 250Hz
45 Hz to 250Hz
45 Hz to 250Hz
Sensitivity 1W@1M
Sensitivity 1W@1M
Sensitivity 1W@1M
98 dB SPL (1W@1M)
98 dB SPL (1W@1M)
98 dB SPL (1W@1M)
Maximum SPL
Maximum SPL
Maximum SPL
132dB Peak
132dB Peak
132dB Peak
Rated Power
Rated Power
Rated Power
1000W – 2000W
1000W – 2000W
1000W – 2000W
Dispersion
Dispersion
Dispersion
Single-driver, 15''
Single-driver, 15''
Single-driver, 15''
Crossover Frequency
Crossover Frequency
Crossover Frequency
40Hz to 120 Hz
40Hz to 120 Hz
40Hz to 120 Hz
Nominal Impedance
Nominal Impedance
Nominal Impedance
8Ω
8Ω
8Ω
LF
LF
LF
15” (380mm), 100mm (4-inch) voice coil, Neodymium magnet B&C custom manufacturing
15” (380mm), 100mm (4-inch) voice coil, Neodymium magnet B&C custom manufacturing
15” (380mm), 100mm (4-inch) voice coil, Neodymium magnet B&C custom manufacturing
B&C & 18Sound
B&C & 18Sound
B&C & 18Sound
Custom speaker
Custom speaker
Custom speaker
FINISH
FINISH
FINISH
Black Polyurea coating
Black Polyurea coating
Black Polyurea coating
Material
Material
Material
Baltic birch wood, Polyurea paint finish
Baltic birch wood, Polyurea paint finish
Baltic birch wood, Polyurea paint finish
Pin Connections Left to right
Pin Connections Left to right
Pin Connections Left to right
2 x NL4MP Speakon 4 pole
2 x NL4MP Speakon 4 pole
2 x NL4MP Speakon 4 pole
DIMENSIONS
DIMENSIONS
DIMENSIONS
(W) 256mm x (H) 410mm x (D) 252mm
(W) 256mm x (H) 410mm x (D) 252mm
(W) 256mm x (H) 410mm x (D) 252mm
WEIGHT
WEIGHT
WEIGHT
39kg (85.9lbs)
39kg (85.9lbs)
39kg (85.9lbs)
Recommended powering solution
Recommended powering solution
Recommended powering solution
PowerSoft T304 : 1 x PISAB115 per bridged channel
PowerSoft T604 : Up to 2 x PISAB115 per channel
PowerSoft T304 : 1 x PISAB115 per bridged channel
PowerSoft T604 : Up to 2 x PISAB115 per channel
PowerSoft T304 : 1 x PISAB115 per bridged channel
PowerSoft T604 : Up to 2 x PISAB115 per channel
