Pisa S8
Pisa S8
Pisa S8
The sound echoed throughout the space
The sound echoed throughout the space
The sound echoed throughout the space
Modern design
Modern design
Modern design
Easy Install
Easy Install
Easy Install
Waterproof
Waterproof
Waterproof
Composed of birch wood
Composed of birch wood
Composed of birch wood
Energetic sound
Energetic sound
Energetic sound
Italian-sourced components
Italian-sourced components
Italian-sourced components
Pisa S8 The sound echoed throughout the space
Pisa S8 The sound echoed throughout the space
Pisa S8 The sound echoed throughout the space
Pisa S8 speakers are designed with sophistication and authenticity, with every detail carefully crafted to deliver the best possible music experience for users.
Pisa S8 speakers are designed with sophistication and authenticity, with every detail carefully crafted to deliver the best possible music experience for users.
Pisa S8 speakers are designed with sophistication and authenticity, with every detail carefully crafted to deliver the best possible music experience for users.
The HF and LF drivers use neodymium technology for clear and crisp highs.
The HF and LF drivers use neodymium technology for clear and crisp highs.
The HF and LF drivers use neodymium technology for clear and crisp highs.
The 100% neodymium drivers create high pressure and high sensitivity, requiring relatively low amplifier power, but producing excellent sound performance.
The 100% neodymium drivers create high pressure and high sensitivity, requiring relatively low amplifier power, but producing excellent sound performance.
The 100% neodymium drivers create high pressure and high sensitivity, requiring relatively low amplifier power, but producing excellent sound performance.
Performance & Technology
Performance & Technology
Performance & Technology
With a MAXSPL of up to 129dB, PISA S8 is not only suitable for home entertainment needs but also an ideal choice for large events such as pubs, lounges, parties, and meetings.
With a MAXSPL of up to 129dB, PISA S8 is not only suitable for home entertainment needs but also an ideal choice for large events such as pubs, lounges, parties, and meetings.
With a MAXSPL of up to 129dB, PISA S8 is not only suitable for home entertainment needs but also an ideal choice for large events such as pubs, lounges, parties, and meetings.
In addition to creating extremely high SPL to serve entertainment needs, PISA S8 can also do something unexpected: it can produce detailed and clear sound at low volume!
In addition to creating extremely high SPL to serve entertainment needs, PISA S8 can also do something unexpected: it can produce detailed and clear sound at low volume!
In addition to creating extremely high SPL to serve entertainment needs, PISA S8 can also do something unexpected: it can produce detailed and clear sound at low volume!
We are truly impressed by the PISA S8 speaker's excellence, which is rare for any other speaker to achieve. The speaker's strength is not just a number, but also a careful consideration of sound quality and user experience.
We are truly impressed by the PISA S8 speaker's excellence, which is rare for any other speaker to achieve. The speaker's strength is not just a number, but also a careful consideration of sound quality and user experience.
We are truly impressed by the PISA S8 speaker's excellence, which is rare for any other speaker to achieve. The speaker's strength is not just a number, but also a careful consideration of sound quality and user experience.
premium quality
premium quality
premium quality
The creativity of the Pisa S8 speakers does not stop at the integration of high-quality components that are researched and manufactured in Italy. The speakers are also coated with Polyurea water-resistant paint, which helps to protect them from the elements. This ensures that the speakers will last longer and perform better in a variety of environments.
The creativity of the Pisa S8 speakers does not stop at the integration of high-quality components that are researched and manufactured in Italy. The speakers are also coated with Polyurea water-resistant paint, which helps to protect them from the elements. This ensures that the speakers will last longer and perform better in a variety of environments.
The creativity of the Pisa S8 speakers does not stop at the integration of high-quality components that are researched and manufactured in Italy. The speakers are also coated with Polyurea water-resistant paint, which helps to protect them from the elements. This ensures that the speakers will last longer and perform better in a variety of environments.
High-end sound quality
High-end sound quality
High-end sound quality
Pisa S8 speakers deliver high-end sound quality that meets the needs of any user. The sound is reproduced clearly and detailed, especially in the high-frequency instruments. The special thing about Pisa S8 is the unique mid-high range that is rare for any 8-inch speaker on the market. The mid-high range is the most "expensive" range of a speaker, and it is the part of the song that is reproduced clearly and distinctly. Pisa S8 uses neodymium technology to produce a maximum SPL of 132dB, which is a very high output for an 8-inch speaker.
Pisa S8 speakers deliver high-end sound quality that meets the needs of any user. The sound is reproduced clearly and detailed, especially in the high-frequency instruments. The special thing about Pisa S8 is the unique mid-high range that is rare for any 8-inch speaker on the market. The mid-high range is the most "expensive" range of a speaker, and it is the part of the song that is reproduced clearly and distinctly. Pisa S8 uses neodymium technology to produce a maximum SPL of 132dB, which is a very high output for an 8-inch speaker.
Pisa S8 speakers deliver high-end sound quality that meets the needs of any user. The sound is reproduced clearly and detailed, especially in the high-frequency instruments. The special thing about Pisa S8 is the unique mid-high range that is rare for any 8-inch speaker on the market. The mid-high range is the most "expensive" range of a speaker, and it is the part of the song that is reproduced clearly and distinctly. Pisa S8 uses neodymium technology to produce a maximum SPL of 132dB, which is a very high output for an 8-inch speaker.
time-tested quality
time-tested quality
time-tested quality
Pisa S8 speakers are not just a sound product, but also a symbol of perfection and creativity in the audio industry. With the unique combination of advanced technology and sophisticated design, Pisa S8 has been conquering the hearts of thousands of music lovers all over the world. Experience it today to feel the power of the refined sound from Pisa S8 speakers!
Pisa S8 speakers are not just a sound product, but also a symbol of perfection and creativity in the audio industry. With the unique combination of advanced technology and sophisticated design, Pisa S8 has been conquering the hearts of thousands of music lovers all over the world. Experience it today to feel the power of the refined sound from Pisa S8 speakers!
Pisa S8 speakers are not just a sound product, but also a symbol of perfection and creativity in the audio industry. With the unique combination of advanced technology and sophisticated design, Pisa S8 has been conquering the hearts of thousands of music lovers all over the world. Experience it today to feel the power of the refined sound from Pisa S8 speakers!
Composed of birch wood
Composed of birch wood
All products in the S series (S8, S12, S15) are made of birch wood, which provides durability over time.
All products in the S series (S8, S12, S15) are made of birch wood, which provides durability over time.
Composed of birch wood
All products in the S series (S8, S12, S15) are made of birch wood, which provides durability over time.
Key Features
Key Features
Key Features
Modern design
Modern design
Modern design
The speaker's minimalist modern design is perfect for any
modern home
The speaker's minimalist modern design is perfect for any modern home
The speaker's minimalist modern design is perfect for any
modern home
Composed of birch wood
Composed of birch wood
Composed of birch wood
Birch wood is a hardwood with high durability, able to withstand impact and scratches. This helps the speaker to be used for a long time without damage.
Birch wood is a hardwood with high durability, able to withstand impact and scratches. This helps the speaker to be used for a long time without damage.
Birch wood is a hardwood with high durability, able to withstand impact and scratches. This helps the speaker to be used for a long time without damage.
Waterproof
Waterproof
Waterproof
Using Polyurea Paint technology, resistant to water and high humidity
Using Polyurea Paint technology, resistant to water and high humidity
Using Polyurea Paint technology, resistant to water and high humidity
Energetic sound
Energetic sound
Energetic sound
Energetic sound will fill the room with deep, rich bass and clear, crisp treble.
Energetic sound will fill the room with deep, rich bass and clear, crisp treble.
Energetic sound will fill the room with deep, rich bass and clear, crisp treble.
Easy install
Easy install
Easy install
The installation is made easy with no high technical skills or very special tools needed to install your device.
The installation is made easy with no high technical skills or very special tools needed to install your device.
The installation is made easy with no high technical skills or very special tools needed to install your device.
Italian-sourced components
Italian-sourced components
Italian-sourced components
Italian-sourced components deliver superior sound quality and performance.
Italian-sourced components deliver superior sound quality and performance.
Italian-sourced components deliver superior sound quality and performance.
Technical Specifications
Technical Specifications
Technical Specifications
Name
Name
Name
PISA S8
PISA S8
PISA S8
Number of ways
Number of ways
Number of ways
2 ways passive
2 ways passive
2 ways passive
Frequency Response
Frequency Response
Frequency Response
60Hz – 20kHz ±3dB
60Hz – 20kHz ±3dB
60Hz – 20kHz ±3dB
Sensitivity 1W@1M
Sensitivity 1W@1M
Sensitivity 1W@1M
99 dB SPL Nominal
99 dB SPL Nominal
99 dB SPL Nominal
Nonimal Peak SPL @1m
Nonimal Peak SPL @1m
Nonimal Peak SPL @1m
127 to 129 dB Peak
127 to 129 dB Peak
127 to 129 dB Peak
Recommended Amplifiers
Recommended Amplifiers
Recommended Amplifiers
400 to 600 Watts ( 8Ω )
400 to 600 Watts ( 8Ω )
400 to 600 Watts ( 8Ω )
HF Dispersion
HF Dispersion
HF Dispersion
90° x 60°
90° x 60°
90° x 60°
Recommended Power
Recommended Power
Recommended Power
RMS 300W / Peak 720W
RMS 300W / Peak 720W
RMS 300W / Peak 720W
Nominal Impedance
Nominal Impedance
Nominal Impedance
8Ω
8Ω
8Ω
LF Woofer
LF Woofer
LF Woofer
8 inch (200mm) / 2.5 inch (64mm) voice coil, Neodymium, B&C custom manufacturing
8 inch (200mm) / 2.5 inch (64mm) voice coil, Neodymium, B&C custom manufacturing
8 inch (200mm) / 2.5 inch (64mm) voice coil, Neodymium, B&C custom manufacturing
HF Driver
HF Driver
HF Driver
1 inch (25mm) / 1.7 inch (44mm) voice coil, Polyimide diaphragm, Neodymium, B&C custom manufacturing
1 inch (25mm) / 1.7 inch (44mm) voice coil, Polyimide diaphragm, Neodymium, B&C custom manufacturing
1 inch (25mm) / 1.7 inch (44mm) voice coil, Polyimide diaphragm, Neodymium, B&C custom manufacturing
B&C & 18Sound
B&C & 18Sound
B&C & 18Sound
Custom speaker
Custom speaker
Custom speaker
Enclosure Material
Enclosure Material
Enclosure Material
Baltic birch wood, Polyurea paint finish
Baltic birch wood, Polyurea paint finish
Baltic birch wood, Polyurea paint finish
Connections
Connections
Connections
2 x NL4MP Speakon 4 pole
2 x NL4MP Speakon 4 pole
2 x NL4MP Speakon 4 pole
DIMENSIONS
DIMENSIONS
DIMENSIONS
(W) 256mm x (H) 446mm x (D) 290mm
(W) 256mm x (H) 446mm x (D) 290mm
(W) 256mm x (H) 446mm x (D) 290mm
WEIGHT
WEIGHT
WEIGHT
10.3kg (22.7lbs)
10.3kg (22.7lbs)
10.3kg (22.7lbs)
Recommended powering solution
Recommended powering solution
Recommended powering solution
PowerSoft T304 : Up to 1 x PISAS8 per channel
PowerSoft T604 : Up to 2 x PISAS8 per channel
PowerSoft T304 : Up to 1 x PISAS8 per channel
PowerSoft T604 : Up to 2 x PISAS8 per channel
PowerSoft T304 : Up to 1 x PISAS8 per channel
PowerSoft T604 : Up to 2 x PISAS8 per channel
Downloads
Downloads
Downloads
English User Manual
English User Manual
English User Manual
Datasheet
Datasheet
Datasheet
EU Declaration of Conformity
EU Declaration of Conformity
EU Declaration of Conformity
IP65 Declaration of Conformity
IP65 Declaration of Conformity
IP65 Declaration of Conformity
